Diesel Portable Rotary Screw Air Compressors

Working Pressure:0.8-1.7 MPa, 116 -246.5 PSI
Free Air Delivery:1.5-40 m³/min, 53 – 1412 CFM
Working Power:23.5-365 kW, 31.5 – 489 HP

Towable Air Compressor Manufacturer:

● Use Germany KAPP machine and German manufacturing technique to process the compression element, the components manufactured to the highest standards and precision aligned roller-bearings ensure long service life with maximum reliability.

● Excellent components, for example, Siemens electronics for high performance.

● Automatic operation system helps the operator to master the operating skills quickly, unattended operation and remote control are available.

● Conform to CE, ISO9001 and energy saving certification, etc.

● Applications: mining, hydropower, oil and gas exploitation, borehole, shipyard, construction, chemical industry, quarry, sandblasting, pipeline pressure test, public works, etc.

Model Rated FAD Rated Pressure Engine Air End Weight Type L×W×H
141SL-15 15 m³/min 15 bar 140 kW Single Stage Compression 2,450 kg 2 wheel 3950x2100x2200 mm
141SLX-15 15 m³/min 15 bar 140 kW Single Stage Compression 2,520 kg 4 wheel 3250×1610×2200 mm
141SL-15B 15 m³/min 15 bar 142kW Single Stage Compression 2,520 kg 4 wheel 3250x1610x2200 mm
145SL-12-18 15/17 m³/min 18/12 bar 140kW Two Stage Compression 2,850 kg 2 wheel 3600x1750x2290 mm
145SLX-12-18S 15/17m³/min 18/12 bar 140 kW Two Stage Compression 2,780 kg 4 wheel 4500x2200x2200 mm
162SL-18 17 m³/min 18 bar 162 kW Two Stage Compression 3.540 kg 4 wheel 3600x1750x2290 mm
40SL-7 4.5 m³/min 7 bar 36.8 kW Single Stage Compression 750kg SKID 1800x1040x1300 mm
40SLX-7 4.5 m³/min 7 bar 36.8 kW Single Stage Compression 860 kg 2 wheel 2400x1330x1550 mm
40SL-8 5 m³/min 8 bar 36.8 kW Single Stage Compression 730 kg 4 wheel 1670x990x1550 mm
110SL-18 12 m³/min 18 bar 118 kw Two Stage Compression 2,300 kg 4 wheel 3700x2100x2160 mm

Diesel Engine

Heavy-duty CUMMINS diesel engine for extended operation.  It can help to improve reliability and reduce fuel consumption.

Diesel Engine

Filters

Nanxiang filter guarantees an extended lifespan and reduces maintenance expenses.

Filters

Compression Element

Utilize the Germany KAPP machine and German manufacturing technique to process the compression element, ensuring that the components are manufactured to the highest standards. Precision aligned roller-bearings guarantee a long service life with maximum reliability.

Compression Element

Chassis

Equipped with a damped chassis and a wear-resistant design.

Chassis

Looking for the Best Compressed Air Solution for your industry?

Get free consultation Now
  • Share your requirements for expert evaluation (multilingual support).
  • Get customized solution, including IP level, air end and parts, screen language, remote control, appearance, voltage and temperature adaptation, etc.
  • Production started after order confirmation (standard production time: 20-25 days).
  • Rigorous quality testing before shipping.
  • Lifelong technical support, original maintenance parts support, and up to 10-year warranty on the air end.
